Ricoh AFICIO MP C305SP Field Service Manual

1. Route the USB cable [A] from the IC card reader as shown above ( x 6).
2. Pull out the USB cable from the rear of the machine in the same way as the installation on the base
machine.
3. Cut out the hole for the USB cable to pass through the upper rear cover [A].
IC Card Reader (External Option)
125
