001 G Color 600 ENG
[0 to 1023 / - / 1digit/step]
002 G Color 1200 ENG
003 BkE ENG [0 to 1023 / - / 1digit/step]
004 BkO ENG [0 to 1023 / - / 1digit/step]
4695
[Black Level Peak Read]
Displays the peak level of the black level scanning.
BE: Blue Even signal, BO: Blue Odd signal
001 B Color 600 ENG
[0 to 1023 / - / 1digit/step]
002 B Color 1200 ENG
4802
[DF Shading FreeRun]
Executes the document feeder shading free run.
001 Lamp OFF
ENG
Turns off the scanner lamp.
[- / - / -]
[Execute]
002 Lamp ON
Turns on the scanner lamp.
[- / - / -]
[Execute]
4803 [Home Position Adjustment]
001 Home Position Adjustment *ENG
Adjusts the scanner home position.
[-1.5 to 1.0 / 0 / 0.1mm/step]
4804 [Home Position]
001 Home Position ENG
Executes the scanner HP detection.
[- / - / -]
[Execute]
4806 [Carriage Save]
Main SP Tables-4
263
