Ricoh AFICIO MP C305SP Field Service Manual

1: Rear
3. Remove the new fusing unit detection fuse [A] if the old blown fuse is attached ( x 1).
4. Connect the fuse connector, and insert the fuse into place from the upper side.
5.
Reassemble the fusing unit.
• Ask your supervisor to obtain the new fusing unit detection fuse.
Fusing
259
