Ricoh AFICIO MP C305SP Field Service Manual

1. Toner Bottle [K]
2. Toner Bottle [C]
3. Toner Bottle [M]
4. Toner Bottle [Y]
5. Image Transfer Belt Unit
6. Fusing Unit
7. Duplex Unit
8. Paper Transfer Roller
9. ID Sensor
10. Image Transfer Belt Cleaning Unit
11. PCDU (Photo Conductor and Development
Unit)
12. LDU 2 (for Magenta, Yellow)
Unit
13. Polygon Mirror Motor 2
14. LDU 1 (for Black, Cyan)
15. Polygon Mirror Motor 1
16. Standard Paper Feed Tray (Tray 1)
1. Product Information
30
