• If you want to use black and white printing, touch "Black & White" on the LCD. If you want to
use color printing, touch "Full Colour" on the LCD.
7. Press the "Start" key to start the test print.
8.
After checking the test pattern, touch "SP Mode" on the LCD to return to the SP mode display.
9. Reset all settings to the default values.
10. Touch "Exit" twice to exit SP mode.
No. Pattern No. Pattern
0 None 12 Independent Pattern (2dot)
1 Vertical Line (1dot) 13 Independent Pattern (4dot)
2 Vertical Line (2dot) 14 Ttrimming Area
3 Horizontal Line (1dot) 15 Hound's Tooth Check (Vertical)
4 Horizontal Line (2dot) 16 Hound's Tooth Check (Horizontal)
5 Grid Vertical Line 17 Band (Vertical)
6 Grid Horizontal Line 18 Band (Horizontal)
7 Grid Pattern Small 19 Checkered Flag Pattern
8 Grid Pattern Large 20 Grayscale (Vertical Margin)
9 Argyle Patter Small 21 Grayscale (Horizontal Margin)
10 Argyle Patter Large 22 Two Beam
11 Independent Pattern (1dot) 23 Full Dot Pattern
Main SP Tables-9
599
