The following keys can be set with the corresponding numbers (The initials in parentheses indicate
the names of the modules).
4-Digit Entries for Keys 1 to 10
Key No. Copy Printer Scanner Web
1 2222 (SCS)
2 14000 (SRM)
3 256 (IMH)
4 1000 (ECS)
5 1025 (MCS)
6 4848 (COPY) 4400 (GPS) 5375 (Scan) 5682 (NFA)
7 2224 (BICU) 4500 (PDL) 5682 (NFA) 6600 (WebDB)
8 4600 (GPS-PM) 3000 (UCS) 3300 (PTS)
9 2000 (NCS) 2000 (NCS) 6666 (WebSys)
10 2224 (BICU) 4126 (DCS) 2000 (NCS)
• The default settings for Keys 1 to 10 are all zero ("0").
Key to Acronyms
Acronym Meaning Acronym Meaning
ECS Engine Control Service NFA Net File Application
GPS GW Print Service PDL Printer Design Language
GSP-PM GW Print Service – Print Module PTS Print Server
IMH Image Memory Handler SCS System Control Service
MCS Memory Control Service SRM System Resource Management
NCS Network Control Service WebDB
Web Document Box
(Document Server)
The machine is now set to record the debugging information automatically on the HDD (the target
selected with SP5857-002) for the events that you selected with SP5858 and the memory modules
selected with SP5859.
Using the Debug Log
621
