No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
-04 D
TD sensor (Vt) upper limit error 1: Ye
The Vt value upper limit of the yellow TD sensor (SP3210-004) exceeds the
specified value (SP3211-002) for the specified number of times (SP3211-003)
consecutively.
• Black, cyan, magenta, or yellow TD sensor disconnected
•
Harness between TD sensor and PCDU defective
•
Defective TD sensor
1. Check the black, cyan, magenta, or yellow TD sensor connector and harness
between the TD sensor and PCDU.
2. Check the drawer connector.
3. Replace the defective TD sensor.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
362
-01
D
TD sensor (Vt) lower limit error: Bk
The Vt value lower limit of the black TD sensor (SP3210-001) falls below the
specified value (SP3211-004) for the specified number of times (SP3211-005)
consecutively.
-02 D
TD sensor (Vt) lower limit error 1: Cy
The Vt value lower limit of the cyan TD sensor (SP3210-002) falls below the
specified value (SP3211-004) for the specified number of times (SP3211-005)
consecutively.
-03 D
TD sensor (Vt) lower limit error 1: Ma
The Vt value lower limit of the magenta TD sensor (SP3210-003) falls below the
specified value (SP3211-004) for the specified number of times (SP3211-005)
consecutively.
-04 D
TD sensor (Vt) lower limit error 1: Ye
The Vt value lower limit of the yellow TD sensor (SP3210-004) falls below the
specified value (SP3211-004) for the specified number of times (SP3211-005)
consecutively.
SC Tables
647
