21. Attach the grounding plate [A] (Upper: (blue) [B] x 1, Lower: x 1 (existing) [C])
22. Attach the rear right cover [A] ( x 3).
23.
Attach the rear upper right cover [B] (M3x10:
x1).
24.
Attach the left cover [C] (from the accessories, not the original cover) (M3x10:
x 2).
25.
Attach the rear upper cover [D] (M3x10:
x 1).
26.
Attach the rear cover [E] (
x 13).
27.
Attach the scanner rear cover [F] (
x 2).
2. Installation
68
