No.
Sensor Name/
Sensor Board Name
Active
CN No./
Pin No.
Condition Symptom
S27 Paper Exit L CN525/7
Open Jam C (Jam 20)
Shorted Jam C (Jam 60)
TH1
Pressure Roller
Thermistor (End)
A CN568/4
Open
SC551
Shorted
TH2
Pressure Roller
Thermistor
A CN568/2
Open
SC571
Shorted
TH3 Fusing Thermistor (End) A CN568/6
Open
SC561
Shorted
TH4
Temperature Detection
Sensor
A CN526/4
Open
SC497
Shorted
SW4
Cover Open/close
Sensor
L CN559/19
Open
“Open Cover” is
displayed.
Shorted
“Open Cover”
cannot be detected.
SW5 Paper tray set sensor L CN543/15
Open
Paper tray cannot
be detected.
Shorted
Paper tray is
detected when the
paper tray is not
set.
SW6
Waste toner bottle set
sensor
L CN535/1
Open
Waste toner bottle
cannot be detected.
Shorted
Waste toner bottle
is detected when
the waste toner
bottle is not set.
Electrical Component Defects
725
