001 Data N: Bk *ENG
Displays the number of sumpling times with end
sensor.
[0 to 9 / - / 1times/step]
002 Data N: C *ENG
003 Data N: M *ENG
004 Data N: Y *ENG
011 Counter n: Bk *ENG
Displays the number of output times of no toner
with end sensor.
[0 to 9 / - / 1times/step]
012 Counter n: C *ENG
013 Counter n: M *ENG
014 Counter n: Y *ENG
021 Latest Output: Bk *ENG
Displays the latest output with end sensor.
[0 or 1 / - / 1/step]
0: Not output, 1: Output
022 Latest Output: C *ENG
023 Latest Output: M *ENG
024 Latest Output: Y *ENG
3124 [TE Sn NE Detect: Set]
001 Data N *ENG
Sets the number of sumpling times.
[1 to 255 / 5 / 1/step]
002 Counter n *ENG
Sets the number of no toner detections.
[1 to 255 / 4 / 1/step]
3130 [TE Sn TE Thresh]
001 Bk *ENG
Sets the number of no toner times for TE
detection.
[0 to 99 / 6 / 1times/step]
002 C *ENG
003 M *ENG
004 Y *ENG
3131 [Vt TE Thresh]
3. SP Mode Tables
176
