Icon Description
Loupe
• Used to change the display magnification.
• Used to move a displayed area.
• See page 46 "Changing the display magnification with the pen".
Switch External
Input
• Displays a screen from a connected device in real time. You can switch the
displayed screen by touching the icon.
• This icon appears when an image from any of the external input terminals
is being displayed.
• The available icons are as follows:
1. When the image from the VGA Input is selected
2. When the image from the DisplayPort Input is selected
3. When the image from the HDMI Input is selected
4. When using the IWB Remote Desktop Software
5. When an externally input image of the whiteboard that is shared by
remote whiteboard is being displayed
6. If the handwritten entry is still displayed when the external input is
disconnected
• See page 80 "Connecting a Computer or Tablet to the Machine".
• See page 109 "Using the Machine to Perform Operations on a Computer
Screen".
• See page 119 "Using a Remote Whiteboard to Share the Screen".
Import to Page
• Captures a screen or an image of the connected device.
• This icon appears when an image from any of the external input terminals
is being displayed.
• See page 80 "Connecting a Computer or Tablet to the Machine".
1. Overview
22
