Printer Service Mode
SM Appendix 8-355 M065/M066
Appendix:
SP Mode
Tables
1007 [Supply Display]
Enables or disables the display for information on each consumable supply.
1007 001 Development
[0 or 1 / 1 / 1 /step]
0: OFF, 1: ON
1007 002 PCU
1007 003 Transfer
1007 004 Int. Transfer
1007 005 Transfer Roller
1007 006 Fuser
1007 007 Fuser Oil
1101 [ToneCtlSet]
1101 001 Tone (Factory)
Recalls a set of gamma settings. This can be
either a) the factory setting, b) the previous
setting, or c) the current setting.
1101 2 Tone (Prev.)
1101 3 Tone (Current)
1102
[ToneCtlSet]
Sets the printing mode (resolution) for the printer gamma adjustment. The
asterisk (*) shows which mode is set.
00: *1200x1200Photo
01: 600x600Text
02: 1200x1200Text
03: 1200x600Text
04: 600x600Photo
05: 1200x600Photo
