Electrical Components
SM 4-65 M095/M096/M099/M100
Replacement
and
Adjustment
4.11.6 FUSING STRIPPER PAWL SOLENOID
1. Open the front cover.
2. Open the top cover.
3. Rear cover (
p.4-5)
4. Right cover (
p.4-7)
5. Fusing stripper pawl solenoid assembly [A] (
x 4, x 1)
