Paper Exit
SM 4-51
M095/M096/M099/M100
Repla
cement
and
Adjustment
4.10 PAPER EXIT
4.10.1 PAPER
EXIT
ROLLER
1.
Operation panel (
p.4-6)
2.
Remove the bushing [A] (
x
1)
3.
Pull out the paper exit roller [B] from th
e ri
ght stay
, and move its left side towards the front
slightly
, and then remove it from the mainframe. (
x
1)
90
92
