Image Transfer
SM 4-29 M095/M096/M099/M100
Replacement
and
Adjustment
4.6.5 ITB (IMAGE TRANSFER BELT) CONTACT SENSOR
1. Right cover ( p.4-7)
2. High voltage power supply board (
p.4-73)
3. ITB contact sensor assembly [A] (
x 1, x 1)
4. ITB contact sensor [B] (hooks x 3)
