Electrical Components
SM 4-67 M095/M096/M099/M100
Replacement
and
Adjustment
4.11.7 FUSING PRESSURE RELEASE SENSOR
1. Fusing stripper pawl solenoid assembly ( p.4-65)
2. Fusing pressure release sensor [B] (
[A] x 1, hooks x 4)
