Ricoh MP 2014AD

SC Code Descriptions
SM 6-19 D245/D246/D247
Troubleshooting
SC No. Level Error Name/Error Condition/Major Cause/Solution
520-00 B Main motor error
"High" signal is detected continuously 20 times or more when
the main motor is turned on.
Detection cycle: 100 msec
 Motor lock due to overload to the drive chain
 Motor driver defective
 Replace the main motor.
SC No. Level Error Name/Error Condition/Major Cause/Solution
522-00 B 2nd tray (option) transport motor error
 Encoder defective
An error is detected when phase A/phase B signals of the
encoder are not input
 Encoder phase pulse over
An error is detected when the phase difference between
phase A and phase B is shifted by more than the specified
number of pulses.
 Rotor restrained time over (overload)
An error is detected when phase A/phase B signals of the
encoder are not input within the predetermined time.
 Transport motor error
 Harness damaged
 Harness not connected correctly
 Main board defective
 Reconnect the harness.
 Replace the harness.
 Replace the main board.
 Replace the transport motor.
