Ricoh MP 2014AD

SC Code Descriptions
SM 6-20 D245/D246/D247
SC No. Level Error Name/Error Condition/Major Cause/Solution
523-00 B 3rd tray (option) transport motor error
 Encoder defective
An error is detected when phase A/phase B signals of the
encoder are not input
 Encoder phase pulse over
An error is detected when the phase difference between
phase A and phase B is shifted by more than the specified
number of pulses.
 Rotor restrained time over (overload)
An error is detected when phase A/phase B signals of the
encoder are not input within the predetermined time.
 Transport motor error
 Harness damaged
 Harness not connected correctly
 Main board defective
 Reconnect the harness.
 Replace the harness.
 Replace the main board.
 Replace the transport motor.
SC No. Level Error Name/Error Condition/Major Cause/Solution
530-00 B Main fan error
A motor lock error is detected for 5 seconds or more when the
main fan is turned on.
Main fan motor defective
Replace the main fan.
