By-pass Tray Cover Type M16
SM 2-23 D245/D246/D247
Installation
9. Remove the front left cover [A] ( x 3).
10. Remove the front cover [A] ( x 6).
11. Cut off the part [A] of the front cover.
 Be careful not to get hurt when cutting off.
12. Attach the front stud bracket (
x 1: M3x6).
13. Attach the rear stud bracket ( x 1: M3x6).
