Rigol DP832 Programming Guide

RIGOL
X DP800 Programming Guide
:TRIGger:OUT:POLArity..................................................................................................... 2-79
:TRIGger:OUT:SIGNal ....................................................................................................... 2-80
:TRIGger:OUT:SOURce ..................................................................................................... 2-80
Chapter 3 Application Examples ........................................................................................ 3-1
CV Output ................................................................................................................................ 3-2
Track Function .......................................................................................................................... 3-2
Timing Output .......................................................................................................................... 3-3
Delay Output ............................................................................................................................ 3-3
To Use the Recorder .................................................................................................................. 3-4
To Use the Analyzer .................................................................................................................. 3-4
To Use the Monitor .................................................................................................................... 3-5
To Use the Trigger ..................................................................................................................... 3-6
Trigger Input ...................................................................................................................... 3-6
Trigger Output .................................................................................................................... 3-6
Chapter 4 Programming Demos ......................................................................................... 4-1
Programming Preparations ......................................................................................................... 4-2
Excel Programming Demo .......................................................................................................... 4-3
Matlab Programming Demo........................................................................................................ 4-7
LabVIEW Programming Demo .................................................................................................... 4-8
Visual Basic Programming Demo .............................................................................................. 4-12
Visual C++ Programming Demo ............................................................................................... 4-14
Chapter 5 Appendix ............................................................................................................ 5-1
Appendix A: Command List ........................................................................................................ 5-1
Appendix B: Factory Setting ....................................................................................................... 5-6
Appendix C: Warranty ............................................................................................................... 5-9
Appendix D: Any Question or Comment? .................................................................................. 5-10

Rigol DP832 Specifications

General

Number of Outputs	3
Output Voltage Range CH1/CH2	0-30V
Output Voltage Range CH3	0-5V
Output Current Range CH1/CH2	0-3A
Output Current Range CH3	0-3A
Total Power	195 W
Power per Channel CH1/CH2	90 W
Power per Channel CH3	15 W
Voltage Resolution	1 mV
Current Resolution	1 mA
Interfaces	USB, RS232
Display	3.5 inch TFT LCD
