Rigol DP832 Programming Guide

RIGOL Chapter 2 Command System
2-40 DP800 Programming Guide
:PRESet:USER[n]:SET:TRACk
Syntax :PRESet:USER[n]:SET:TRACk {ON|OFF}
:PRESet:USER[n]:SET:TRACk?
Description Enable or disable the track function of the specified user-preset state.
Query the status of the track function of the specified user-preset state.
Parameter
Name Type Range Default
[n] Discrete 1|2|3|4 None
{ON|OFF} Bool ON|OFF OFF
Explanation  By default, this command sets the parameter of the channel currently selected.
If you want to set the parameter of other channel, please use
the
:INSTrument[:SELEct] command to select the desired channel.
 This command is only applicable to channels supporting the track function:
CH2 and CH3 of DP831A as well as CH1 and CH2 of DP832A/DP832. For
channels that do not support the track function, the query returns NONE.
Return Format The query returns ON or OFF. For channels that do not support the track function,
the query returns NONE.
Example :PRES:USER1:SET:TRAC ON
:PRES:USER1:SET:TRAC?
:PRESet:USER[n]:SET:OCP
Syntax :PRESet:USER[n]:SET:OCP {ON|OFF}[,<current>|MINimum|MAXimum]
:PRESet:USER[n]:SET:OCP? [MINimum|MAXimum]
Description Enable or disable the overcurrent protection function of the specified user-preset
state and set the overcurrent protection limit.
Query the status and limit of the overcurrent protection function of the specified
user-preset state.
Parameter
Name Type Range Default
[n] Discrete 1|2|3|4 None
{ON|OFF} Bool ON|OFF OFF
<current> Real
Current range of the
current channel
Maximum current of the
current channel
Explanation By default, this command sets the parameter of the channel currently selected. If
you want to set the parameter of other channel, please use
the
:INSTrument[:SELEct] command to select the desired channel.
Return Format The query returns OFF or ON,limit of overcurrent protection, for example,
ON,1.5000.
Example :PRES:USER1:SET:OCP ON,1.5
:PRES:USER1:SET:OCP?

Rigol DP832 Specifications

General

Number of Outputs	3
Output Voltage Range CH1/CH2	0-30V
Output Voltage Range CH3	0-5V
Output Current Range CH1/CH2	0-3A
Output Current Range CH3	0-3A
Total Power	195 W
Power per Channel CH1/CH2	90 W
Power per Channel CH3	15 W
Voltage Resolution	1 mV
Current Resolution	1 mA
Interfaces	USB, RS232
Display	3.5 inch TFT LCD
