Rigol DP832 Programming Guide

RIGOL Chapter 2 Command System
2-26 DP800 Programming Guide
:MONItor:CURRent[:VALue]
Syntax :MONItor:CURRent[:VALue] {<value>|MINimum|MAXimum}
:MONItor:CURRent[:VALue]? [MINimum|MAXimum]
Description Set the current of the monitor condition.
Query the current of the monitor condition.
Parameter
Name Type Range Default
<value> Real
0 to the maximum
current of the current
channel
0.5*rated current of
the current channel
Return Format The query returns the current of the monitor condition, for example, 4.0000.
Example :MONI:CURR 4 /*Set the current of the monitor condition to 4A*/
:MONI:CURR? /*Query the current of the monitor condition and the query
returns 4.0000*/
Related
Commands
:MONItor:CURRent:CONDition
:MONItor:POWER:CONDition
:MONItor:POWER[:VALue]
:MONItor:VOLTage:CONDition
:MONItor:VOLTage[:VALue]
:MONItor:POWER:CONDition
Syntax :MONItor:POWER:CONDition {<P|>P|NONE}
:MONItor:POWER:CONDition?
Description Set the power monitor condition of the monitor to “<Power” or “>Power”. NONE
indicates that no power monitor condition will be set.
Query the power monitor condition of the monitor.
Parameter
Name Type Range Default
{<P|>P|NONE} Discrete <P|>P|NONE NONE
Explanation  After setting the power monitor condition, sending
the
:MONItor:POWER[:VALue] command can set the power value.
 The actual monitor condition is the logic combination of the voltage, current
and power.
Return Format The query returns “condition”, for example, <P.
Example :MONI:POWER:COND <P /*Set the power monitor condition to “<Power”*/
:MONI:POWER:COND? /*Query the current power monitor condition and the
query returns <P*/
Related
Commands
:MONItor:POWER[:VALue]
:MONItor:CURRent:CONDition
:MONItor:CURRent[:VALue]
:MONItor:VOLTage:CONDition
:MONItor:VOLTage[:VALue]

Rigol DP832 Specifications

General

Number of Outputs	3
Output Voltage Range CH1/CH2	0-30V
Output Voltage Range CH3	0-5V
Output Current Range CH1/CH2	0-3A
Output Current Range CH3	0-3A
Total Power	195 W
Power per Channel CH1/CH2	90 W
Power per Channel CH3	15 W
Voltage Resolution	1 mV
Current Resolution	1 mA
Interfaces	USB, RS232
Display	3.5 inch TFT LCD
