Rigol DP832 Programming Guide

RIGOL Chapter 2 Command System
2-36 DP800 Programming Guide
:OUTPut:TRACk
Syntax :OUTPut:TRACk {CH1|CH2|CH3},{ON|OFF}
:OUTPut:TRACk? [{CH1|CH2|CH3}]
Description Enable or disable the track function of the specified channel.
Query the status of the track function of the specified channel.
Parameter
Name Type Range Default
{CH1|CH2|CH3} Discrete CH1|CH2|CH3 None
{ON|OFF} Bool ON|OFF OFF
Explanation  This command is only applicable to channels supporting the track function:
CH2 and CH3 of DP831A as well as CH1 and CH2 of DP832A/DP832. For
channels that do not support the track function, the query returns NONE.
 For two channels supporting the track function, when the track function of one
channel (the tracked channel) is enabled, the voltage setting value of the other
channel (the tracking channel, the track status label (for example,
) is
displayed in the display area corresponding to this channel and the voltage
value can not be set) will change accordingly when the voltage setting value of
this channel is changed.
 By default, the track function is disabled and it is usually used to provide
symmetric voltage for the calculation amplifier or other circuits.
 The track function only tracks the voltage setting value and the actual output
voltage will not be affected.
Return Format The query returns ON or OFF. For channels that do not support the track function,
the query returns NONE.
Example :OUTP:TRAC CH1,ON
:OUTP:TRAC? CH1

Rigol DP832 Specifications

General

Number of Outputs	3
Output Voltage Range CH1/CH2	0-30V
Output Voltage Range CH3	0-5V
Output Current Range CH1/CH2	0-3A
Output Current Range CH3	0-3A
Total Power	195 W
Power per Channel CH1/CH2	90 W
Power per Channel CH3	15 W
Voltage Resolution	1 mV
Current Resolution	1 mA
Interfaces	USB, RS232
Display	3.5 inch TFT LCD
