Rigol DP832 Programming Guide

RIGOL Chapter 2 Command System
2-12 DP800 Programming Guide
:DISPlay Command
Syntax :DISPlay:MODE {NORMal|WAVE|DIAL}
:DISPlay:MODE?
Description Set the display mode to normal, wave or dial.
Query the current display mode.
Parameter
Name Type Range Default
{NORMal|WAVE|DIAL} Discrete NORMal|WAVE|DIAL NORMal
Explanation  NORMal: normal mode. The parameters (such as the voltage and current) of all
the channels are displayed in number format.
 WAVE: waveform mode. The parameters (such as the voltage and current) of
the channel currently selected are displayed in both waveform and number
formats.
 DIAL: dial mode. The parameters (such as the voltage and current) of the
channel currently selected are displayed in both dial and number formats.
Return Format The query returns NORMAL, WAVE or DIAL.
Example :DISP:MODE WAVE /*Select the waveform display mode*/
:DISP:MODE? /*Query the current display mode and the query returns WAVE */

Rigol DP832 Specifications

General

Number of Outputs	3
Output Voltage Range CH1/CH2	0-30V
Output Voltage Range CH3	0-5V
Output Current Range CH1/CH2	0-3A
Output Current Range CH3	0-3A
Total Power	195 W
Power per Channel CH1/CH2	90 W
Power per Channel CH3	15 W
Voltage Resolution	1 mV
Current Resolution	1 mA
Interfaces	USB, RS232
Display	3.5 inch TFT LCD
