Rigol DP832 Programming Guide

RIGOL Chapter 2 Command System
2-72 DP800 Programming Guide
:TIMEr:TEMPlet:POINTs
Syntax :TIMEr:TEMPlet:POINTs <value>
:TIMEr:TEMPlet:POINTs?
Description Set the total number of points.
Query the total number of points.
Parameter
Name Type Range Default
<value> Integer 10 to 2048 10
Explanation  The total number of points refers to the number of groups of timer parameters
created using the templet currently selected.
 When the total number of points (denoted by P) and the current number of
output groups (denoted by G) are different, P groups of parameters will be
created using the templet; then, the number of output groups will change to P
automatically.
Return Format The query returns an integer from 10 to 2048, for example, 50.
Example :TIME:TEMP:POINT 50
:TIME:TEMP:POINT?
Related
Command
:TIMEr:TEMPlet:SELect
:TIMEr:TEMPlet:RISERate
Syntax :TIMEr:TEMPlet:RISERate <value>
:TIMEr:TEMPlet:RISERate?
Description Set the rise index of ExpRise.
Query the rise index of ExpRise.
Parameter
Name Type Range Default
<value> Integer 0 to 10 0
Explanation When the templet currently selected is ExpRise or ExpFall, the timer parameters
created cannot reach the maximum or minimum due to the characteristic of the
exponential function. The range of the timer parameters created is related to the
rise index or fall index currently set. The larger the rise index or fall index is, the
larger the range of the timer parameters will be.
Return Format The query returns an integer from 0 to 10, for example, 5.
Example :TIME:TEMP:RISER 5
:TIME:TEMP:RISER?
Related
Command
:TIMEr:TEMPlet:SELect

Rigol DP832 Specifications

General

Number of Outputs	3
Output Voltage Range CH1/CH2	0-30V
Output Voltage Range CH3	0-5V
Output Current Range CH1/CH2	0-3A
Output Current Range CH3	0-3A
Total Power	195 W
Power per Channel CH1/CH2	90 W
Power per Channel CH3	15 W
Voltage Resolution	1 mV
Current Resolution	1 mA
Interfaces	USB, RS232
Display	3.5 inch TFT LCD
