Rigol DP832 Programming Guide

RIGOL Chapter 2 Command System
2-48 DP800 Programming Guide
[:SOURce[n]]:CURRent:PROTection:STATe
Syntax [:SOURce[n]]:CURRent:PROTection:STATe {ON|OFF}
[:SOURce[n]]:CURRent:PROTection:STATe?
Description Enable or disable the overcurrent protection function of the specified channel.
Query the status of the overcurrent protection function of the specified channel.
Parameter
Name Type Range Default
[n] Integer 1|2|3 1
{ON|OFF} Bool ON|OFF OFF
Explanation  When the overcurrent protection function is enabled, the output turns off
automatically when the output current exceeds the overcurrent protection limit
currently set. You can send the
:OUTPut:OCP:QUES? command to query
whether overcurrent protection occurs to the specified channel.
 The function of this command is equivalent to that of
the
:OUTPut:OCP[:STATe] command.
 When [:SOURce[n]] is omitted, the command sets the parameter of the
channel currently selected by default.
Return Format The query returns ON or OFF.
Example :CURR:PROT:STAT ON
:CURR:PROT:STAT?
Related
Commands
:OUTPut:OCP:QUES?
:OUTPut:OCP[:STATe]
:OUTPut:OCP:VALue
[:SOURce[n]]:VOLTage[:LEVel][:IMMediate][:AMPLitude]
Syntax [:SOURce[n]]:VOLTage[:LEVel][:IMMediate][:AMPLitude]
{<voltage>|MINimum|MAXimum}
[:SOURce[n]]:VOLTage[:LEVel][:IMMediate][:AMPLitude]?
[{MINimum|MAXimum}]
Description Set the voltage of the specified channel.
Query the voltage of the specified channel.
Parameter
Name Type Range Default
[n] Integer 1|2|3 1
<voltage> Real Refer to the “Explanation” of :APPLy Command
Explanation When [:SOURce[n]] is omitted, the command sets the parameter of the channel
currently selected by default.
Return Format The query returns the voltage of the specified channel, for example, 8.500.
Example :VOLT 8.5
:VOLT?
Related
Command
:APPLy Command

Rigol DP832 Specifications

General

Number of Outputs	3
Output Voltage Range CH1/CH2	0-30V
Output Voltage Range CH3	0-5V
Output Current Range CH1/CH2	0-3A
Output Current Range CH3	0-3A
Total Power	195 W
Power per Channel CH1/CH2	90 W
Power per Channel CH3	15 W
Voltage Resolution	1 mV
Current Resolution	1 mA
Interfaces	USB, RS232
Display	3.5 inch TFT LCD
