Rigol DP832 Programming Guide

Chapter 2 Command System RIGOL
DP800 Programming Guide 2-29
:MONItor:VOLTage:CONDition
Syntax :MONItor:VOLTage:CONDition {<V|>V|NONE},{AND|OR|NONE}
:MONItor:VOLTage:CONDition?
Description Set the voltage monitor condition of the monitor.
Query the voltage monitor condition of the monitor.
Parameter
Name Type Range Default
{<V|>V|NONE} Discrete <V|>V|NONE NONE
{AND|OR|NONE} Discrete AND|OR|NONE NONE
Explanation  After setting the voltage monitor condition, sending
the
:MONItor:VOLTage[:VALue] <value> command can set the voltage value.
 You can set the voltage monitor condition to “<Volt” ot “>Volt”.
 The actual monitor condition is the logic combination of the voltage, current
and power. You need to set the logic relation between the voltage monitor
condition and the current/power monitor conditions; you can set the logic
relation to “AND”, “OR” or “None”; wherein, “None” indicates that no logic
relation will be set.
Return Format The query returns “condition,logic relation”, for example, <V,AND.
Example :MONI:VOLT:COND <V,AND /*Set the voltage monitor condition to “<Volt” and
logic relation to “AND”*/
:MONI:VOLT:COND? /*Query the current voltage monitor condition and
the query returns <V,AND*/
Related
Commands
:MONItor:CURRent:CONDition
:MONItor:CURRent[:VALue]
:MONItor:POWER:CONDition
:MONItor:POWER[:VALue]
:MONItor:VOLTage[:VALue]

Rigol DP832 Specifications

General

Number of Outputs	3
Output Voltage Range CH1/CH2	0-30V
Output Voltage Range CH3	0-5V
Output Current Range CH1/CH2	0-3A
Output Current Range CH3	0-3A
Total Power	195 W
Power per Channel CH1/CH2	90 W
Power per Channel CH3	15 W
Voltage Resolution	1 mV
Current Resolution	1 mA
Interfaces	USB, RS232
Display	3.5 inch TFT LCD
