Rigol DP832 Programming Guide

RIGOL Chapter 1 Programming Overview
1-6 DP800 Programming Guide
Besides, many commands contain the MINimum and MAXimum parameters which are used to set the
parameter to its minimum or maximum value. For example, MINimum and MAXimum in
the :SYSTem:BRIGhtness {<brightness>|MINimum|MAXimum} command are used to set the brightness to
the minimum or maximum.
Command Abbreviation
All the commands are case-insensitive and you can use any of them. If abbreviation is used, all the capital
letters in the command must be written completely. For example, the :ANALyzer:ANALyze command can be
abbreviated to :ANAL:ANAL.

Rigol DP832 Specifications

General

Number of Outputs	3
Output Voltage Range CH1/CH2	0-30V
Output Voltage Range CH3	0-5V
Output Current Range CH1/CH2	0-3A
Output Current Range CH3	0-3A
Total Power	195 W
Power per Channel CH1/CH2	90 W
Power per Channel CH3	15 W
Voltage Resolution	1 mV
Current Resolution	1 mA
Interfaces	USB, RS232
Display	3.5 inch TFT LCD
