Rigol DP832 Programming Guide

Chapter 2 Command System RIGOL
DP800 Programming Guide 2-47
[:SOURce[n]]:CURRent:PROTection[:LEVel]
Syntax [:SOURce[n]]:CURRent:PROTection[:LEVel] {<current>|MINimum|MAXimum}
[:SOURce[n]]:CURRent:PROTection[:LEVel]? [{MINimum|MAXimum}]
Description Set the overcurrent protection limit of the specified channel.
Query the overcurrent protection limit of the specified channel.
Parameter
Name Type Range Default
[n] Integer 1|2|3 1
<current> Real
Current range of the
current channel
Maximum current of the
current channel
Explanation  When the overcurrent protection function is enabled, the output turns off
automatically when the output current exceeds the overcurrent protection limit
currently set. You can send the
:OUTPut:OCP:QUES? command to query
whether overcurrent protection occurs to the specified channel currently.
 The function of this command is equivalent to that of the
:OUTPut:OCP:VALue
command.
 When [:SOURce[n]] is omitted, the command sets the parameter of the
channel currently selected by default.
Return Format The query returns the overcurrent protection limit, for example, 5.0000.
Example :CURR:PROT 5
:CURR:PROT?
Related
Commands
:OUTPut:OCP:QUES?
:OUTPut:OCP[:STATe]
:OUTPut:OCP:VALue

Rigol DP832 Specifications

General

Number of Outputs	3
Output Voltage Range CH1/CH2	0-30V
Output Voltage Range CH3	0-5V
Output Current Range CH1/CH2	0-3A
Output Current Range CH3	0-3A
Total Power	195 W
Power per Channel CH1/CH2	90 W
Power per Channel CH3	15 W
Voltage Resolution	1 mV
Current Resolution	1 mA
Interfaces	USB, RS232
Display	3.5 inch TFT LCD
