Rigol DP832 Programming Guide

Chapter 2 Command System RIGOL
DP800 Programming Guide 2-1
Chapter 2 Command System
This chapter introduces the syntax, function, parameter and using instruction of each DP800 command in
A-Z order.
Main topics of this chapter:
 :ANALyzer Commands
 :APPLy Command
 :DELAY Commands
 :DISPlay Command
 IEEE488.2 Common Commands
 :INSTrument Commands
 :MEASure Commands
 :MEMory Commands
 :MMEMory Commands
 :MONItor Commands
 :OUTPut Commands
 :PRESet Commands
 :RECorder Commands
 :SOURce Commands
 :SYSTem Commands
 :TIMEr Commands
 :TRIGger Commands
Explanation: In this command system, setting commands relating to the time, voltage, current and power
parameters can be sent with units. Unless otherwise noted, the units available and the default unit of each
parameter are as shown in the table below.
Parameter Type
Units Available
Default Unit
Time s
[1]
s
Voltage
V, mV
V
Current A, mA A
Power
W, mW
W
Note
[1]
: For the :TRIGger:OUT:PERIod [D0|D1|D2|D3,]<value> command (setting the period of the
square waveform of trigger output), <value> is a time parameter and the units available are s, ms and us.
The default unit is s.

Rigol DP832 Specifications

General

Number of Outputs	3
Output Voltage Range CH1/CH2	0-30V
Output Voltage Range CH3	0-5V
Output Current Range CH1/CH2	0-3A
Output Current Range CH3	0-3A
Total Power	195 W
Power per Channel CH1/CH2	90 W
Power per Channel CH3	15 W
Voltage Resolution	1 mV
Current Resolution	1 mA
Interfaces	USB, RS232
Display	3.5 inch TFT LCD
