Content Conventions in this Manual:
DP800 series programmable linear DC power supply includes the following models. The programmable
ranges of the voltage and current for each model are as listed below. Unless otherwise noted, in this
manual, DP831A is taken as an example to illustrate the using method of each DP800 series command.
DP831A
Channel Voltage Range Voltage Default Current Range Current Default
CH1 0V to 8.4V 0V 0A to 5.3A 5A
CH2 0V to 32V 0V 0A to 2.1A 2A
CH3 -32V to 0V 0V 0A to 2.1A 2A
DP832A/DP832
Channel Voltage Range Voltage Default Current Range Current Default
CH1 0V to 32V 0V 0A to 3.2A 3A
CH2 0V to 32V 0V 0A to 3.2A 3A
CH3 0V to 5.3V 0V 0A to 3.2A 3A

Rigol DP832 Specifications

General

Number of Outputs	3
Output Voltage Range CH1/CH2	0-30V
Output Voltage Range CH3	0-5V
Output Current Range CH1/CH2	0-3A
Output Current Range CH3	0-3A
Total Power	195 W
Power per Channel CH1/CH2	90 W
Power per Channel CH3	15 W
Voltage Resolution	1 mV
Current Resolution	1 mA
Interfaces	USB, RS232
Display	3.5 inch TFT LCD
