Chapter 11 Protocol Decoding RIGOL
MSO7000/DS7000 User Guide 11-3
Falling : samples the channel data on the falling edge of the clock.
Both : samples the channel data on both the rising edge and the
falling edge of the clock.
⚫ Set the threshold
When the clock signal is an analog channel (CH1-CH4), you need to set a
threshold. Press Threshold, rotate the multifunction knob or use the
pop-up numeric keypad to set the threshold.
3． Bus setting
Press Bus to enter the bus setting menu.
⚫ Set the bus
Press BUS to select the digital bus for Parallel decoding, as shown in the
following table.
Bus
Width
Bit X
Channel
Remarks
CH1
1
0
CH1
Width, Bit X, and CH are set
automatically, and you cannot
modify them.
CH2
1
0
CH2
Width, Bit X, and CH are set
automatically, and you cannot
modify them.
CH3
1
0
CH3
Width, Bit X, and CH are set
automatically, and you cannot
modify them.
CH4
1
0
CH4
Width, Bit X, and CH are set
automatically, and you cannot
modify them.
D7-D0
8
0 (default)
D7
(default)
Bit0 to Bit7 are set to D7 to D0
respectively. Width is set
automatically, and you cannot
modify them.
D15-D8
8
0 (default)
D15
(default)
Bit0 to Bit7 are set to D15 to D8
respectively. Width is set
automatically, and you cannot
modify them.
D15-D0
16
0 (default)
D15
(default)
Bit0 to Bit15 are set to D15 to
D0 respectively. Width is set
automatically, and you cannot
modify them.
D0-D7
8
0 (default)
D0
(default)
Bit0 to Bit7 are set to D0 to D7
respectively. Width is set
automatically, and you cannot
modify them.
