Chapter 1 Quick Start RIGOL
MSO7000/DS7000 User Guide 1-33
Method 3: Enable the touch screen and tap the desired help option to get the
corresponding help information.
To View the Option Information and the Option
Installation
MSO7000/DS7000 series oscilloscope provides multiple options to fulfill your
measurement requirements. If you need any of these options, order them according
to the Order No. available in "Appendix A: Accessories and Options", and then
install the options according to this section. Besides, you can also view the options
currently installed on the oscilloscope or activate the newly purchased option.
1. View the installed option
The instrument is installed with the trial versions of the options before leaving
factory. When you power on the instrument for the first time, the trial time is
about 2,160 minutes. If your instrument has currently installed the option,
perform the following operations to view the name of the installed option and
other detailed information about the option from the option list.
Tip
⚫ Help information for other keys and buttons:
➢ Power key: powers on/off the instrument.
➢ Menu Off key: displays or hides menus. Pressing this key can hide the
menus.
➢ Back key: returns to the previous menu or last set function menu.
➢ Multifunction knob : In non-menu-operation mode, rotate this knob to
adjust the brightness of waveform display. When you operate on the
menu, this knob is illuminated. For the menu that has multiple
sub-menus, press the corresponding softkey of the sub-menu, and then
rotate this knob to select the specified parameter item and press down
the knob to select it (sometimes you need to rotate the knob to select the
parameter item). It can also be used to modify parameters, input a
filename, etc.
➢ Wave Vertical POSITION: rotating the knob can adjust the
vertical position of the waveform of the current digital channel, the
vertical position of the math operation waveform, the vertical position of
the reference waveform, or the vertical display position of the decoding
bus.
➢ Wave Vertical SCALE: rotating the knob can adjust the vertical
scale of the math operation waveform or the vertical scale of the
reference waveform; adjust the display size of the waveform of the digital
channel.
⚫ If the menu item is grayed out, you cannot press the corresponding
front-panel menu key to obtain the help information. What you can do is only
to follow the above Method 2 or 3 to get the help information.
