Chapter 19 System Utility Function Setting RIGOL
MSO7000/DS7000 User Guide 19-5
Apply the Network Parameter Setting
Press Apply to apply the current network parameter setting.
MAC address
For each oscilloscope, the MAC address is unique. When assigning the IP address for
the oscilloscope, the system uses the MAC address to identify the instrument.
VISA Address
Displays the VISA address currently used by the oscilloscope.
Online control information
Displays the user name and password for network configuration of the oscilloscope
through the LXI webpage.
Tip: Connect the oscilloscope to the local area network. Start up Ultra Sigma, and
then right-click the resource name and select "LXI-Web" to load the LXI webpage.
You can also directly input the IP address of the oscilloscope into the address bar of
the browser to load the LXI webpage.
To Set mDNS
Press mDNS continuously to enable or disable the multicast Domain Name System
(mDNS). This system is used to provide the function of DNS server for service
discovery in a small network without a DNS server.
To Set Host Name
Press Host Name to input the host name. For the hostname input method, refer to
relevant descriptions in "To Create a Folder".
Tip
⚫ When the three IP configuration types are all turned on, the priority of the
parameter configuration from high to low is "DHCP", "Auto IP", and "Static
IP".
⚫ The three IP configuration types cannot be all turned off at the same time.
