Search Function
The search function enables you to search the channel edge, Pulse trigger, Runt
trigger, Slope trigger, RS232 trigger, I2C trigger, or SPI trigger. Press Search on the
front panel to enable the search setting menu. You can also enable the touch screen
and then tap the function navigation icon at the lower-left corner of the screen
to open the function navigation. Then, tap the "Search" icon to open the search
setting menu.
1. Enable or Disable the Search Function
Press Search continuously to enable or disable the search function.
2. Select the Search Type and Set the Parameters
Press Type, and rotate the multifunction knob to select the desired type
(Edge, Pulse, Runt, Slope, RS232, I2C, or SPI). You can also press Type
continuously or enable the touch screen to select it.
⚫ Edge: Press Type to select "Edge" as the search type. For Edge Setup
menu settings, refer to descriptions in "Edge Trigger". Press Threshold
to enter the threshold setting menu. Rotate the multifunction knob or
use the pop-up numeric keypad to set the threshold.
⚫ Pulse: Press Type to select "Pulse" as the search type. For Pulse Setup
menu settings, refer to descriptions in "Pulse Trigger". Press Threshold
to enter the threshold setting menu. Rotate the multifunction knob or
use the pop-up numeric keypad to set the threshold.
⚫ Runt: Press Type to select "Runt" as the search type. For Runt Setup
menu settings, refer to descriptions in "Runt Trigger". Press Threshold
to enter the threshold setting menu. Rotate the multifunction knob or
use the pop-up numeric keypad to set Threshold A and Threshold B.
⚫ Slope: Press Type to select "Slope" as the search type. For Slope Setup
menu settings, refer to descriptions in "Slope Trigger". Press Threshold
to enter the threshold setting menu. Rotate the multifunction knob or
use the pop-up numeric keypad to set Threshold A and Threshold B.
⚫ RS232: Press Type to select "RS232" as the search type. For RS232
Setup menu settings, refer to descriptions in "RS232 Trigger (Option)".
Press Threshold to enter the threshold setting menu. Rotate the
multifunction knob or use the pop-up numeric keypad to set the
threshold.
⚫ I2C: Press Type to select "I2C" as the search type. For I2C Setup menu
settings, refer to descriptions in "I2C Trigger (Option)". Press
Threshold to enter the threshold setting menu. Rotate the multifunction
