Chapter 11 Protocol Decoding RIGOL
MSO7000/DS7000 User Guide 11-5
Press Endian continuously to select "Normal" or "Invert" as the endian of
the bus.
âš« Polarity
Press Polarity continuously to select Positive or Negative as the
polarity for data decoding.
4． Display-related setting
Press Display to enter the display setting menu.
âš« Set the display format
Press Format, rotate the multifunction knob to select the display
format of the bus data. Then, press down the knob to select it. You can also
press Format continuously or enable the touch screen to select it. The
available display formats of the bus data are "Hex", "Dec", "Bin", and
"ASCII".
âš« Adjust the vertical position of the bus
Press Position, and then rotate the multifunction knob to adjust the
vertical display position of the bus. You can also rotate Wave Vertical
POSITION to adjust the vertical display position of the bus.
âš« Set the label display
Press Label to enable or disable the label display of the Parallel decoding
bus. When enabled, the bus label "Parallel" will be displayed at the
upper-left side of the bus (when the bus display is enabled).
âš« Event table
Press Event Table to enter the event table setting menu. The event table
displays the detailed decoding information in time order in the form of a
table, so as to better observe the long decoded data. The decoding
information includes the decoded data, the corresponding line number, and
time information.
➢ Open or close the event table: Press Event Table continuously to
enable or disable the event table. When you enable the event table,
the following figure is displayed, as shown in Figure 11-2. You can also
enable the touch screen to tap the icon at the upper-right corner of
the table to close the event table. Besides, when the running status is
"STOP", you can also rotate the multifunction knob to select a
specified line and view the corresponding decoding information.
