4
Controls and features
Control section
START/STOP key
PAUSE/CONT key
DISPLAY key
LIGHT key
POWER key
MENU/ENTER key
OUTPUT CAL key
X/Y/Z/XYZ key
RANGE key
RECALL key
MAX HOLD RESET key
key
Indicator LED
RANGE keys
These keys control the level range for the X, Y, Z axis.
The
key switches the level range up, and the key switches the level
range down.
The following two settings are available: [0.0001 to 1], [0.001 to 10]
X / Y / Z / XYZ key
Switches the vibration axis to be shown on the display.
With each push of the key, the display cycles through the settings in the
order X Y Z XYZ X etc.
RECALL key
Transition from measurement screen to recall screen.
MAX HOLD RESET key
Resets the value of the max hold function.
START / STOP key
Serves to start / stop the measurement (store).
