Rion VM-56 - Displacement Frequency Response Characteristics

154
Reference Information
Displacement frequency response characteristics
0.1 1 10 100 1000
40
30
20
10
0
-10
-20
-30
-40
-50
-60
-70
-80
Frequency (Hz)
Relative Acceleration Response (dB)
Lower limit:0.5 Hz
Lower limit:1.0 Hz
Lower limit:4.0 Hz
Acceleration waveform processed by second-order integral  lter.
The  lter characteristics with  at velocity are as shown below.
0.1 1 10 100 1000
40
30
20
10
0
-10
-20
-30
-40
-50
-60
-70
-80
Frequency (Hz)
Relative Displacement Response (dB)
Lower limit:0.5 Hz
Lower limit:1.0 Hz
Lower limit:4.0 Hz
1
