63
Measurement
Procedure example of the measurement
(1) Check that an SD card is inserted into the unit. Then, press the
POWER key to start the unit.
(2) Press the MENU/ENTER key. The menu list screen appears. As
necessary, set the time and other parameters.
(3) On the menu list screen, select the Store menu, and then set the Store
modes. In addition, set a measurement time and other parameters on
each Store mode.
(4) Return to the current screen. As necessary, select the desired screen
by using the display key and the X/Y/Z/XYZ keys.
(5) Using the RANGE key, set ranges for the X-, Y-, and Z-axis.
(6) To start measurement, press the START/STOP key. To end measure-
ment, press the START/STOP key again.
Note
The delay of 2 seconds occurs from when vibration is
measured until it is displayed.
