19
Preparations
Vibration Pickup placement
Install the sensor on a solid horizontal plane. As necessary, fasten the sensor
with bolts on the vibrating surface.
Important
Avoid locations exposed to direct sunlight or
to drastic temperature changes. Such condi-
tions can cause changes in Vibration pickup
sensitivity, which will impair the accuracy of
measurement results.
Vibration Pickup connection
Insert the input connector into the tip connector of the pickup and turn the
ring clockwise to x.
Important
The Vibration Pickup is a precision device. Never
drop it or subject it to shocks.
