14 WisDom User Manual
LED Indicators
The six LED indicators found at the upper left provide typical system
indications, as discussed below. Some indicators have additional
functions, which are explained later on.
Power LED
The Power LED indicates system operation.
Condition Description
ON
The system is operating properly from mains
(AC) power and its backup battery is in good
condition.
OFF
No power to the system (Mains or Battery)
RAPID FLASH
Indicates mains power fault.
SLOW FLASH
Indicates Battery fault or being in the user
menu.
Set LED
The Set LED indicates whether or not the system intrusion detectors
are set.
Condition Description
ON
The system is fully or partially set.
OFF
The system is fully unset.
SLOW FLASH
The system is in its Exit Delay time period.
RAPID FLASH
Indicates an alarm condition or after
unsetting an alarmed system while the
display is in Alarm Memory mode. To
restore the display to Normal Operation
mode, press
.
