Publication 1769-UM002B-EN-P - July 2005
Module Diagnostics and Troubleshooting 5-11
1769-OF8C and
-OF8V Specific
Configuration
Error
X41A 010 0 0001 1010 invalid idle value (channel 1)
X41B 010 0 0001 1011 invalid idle value (channel 2)
X41C 010 0 0001 1100 invalid idle value (channel 3)
X41D 010 0 0001 1011 invalid idle value (channel 4)
X41E 010 0 0001 1100 invalid idle value (channel 5)
X41F 010 0 0001 1101 invalid idle value (channel 6)
X420 010 0 0010 0000 invalid idle value (channel 7)
X421 010 0 0010 0001 invalid clamps (channel 0)
X422 010 0 0010 0010 invalid clamps (channel 1)
X423 010 0 0010 0011 invalid clamps (channel 2)
X424 010 0 0010 0100 invalid clamps (channel 3)
X425 010 0 0010 0101 invalid clamps (channel 4)
X426 010 0 0010 0110 invalid clamps (channel 5)
X427 010 0 0010 0111 invalid clamps (channel 6)
X428 010 0 0010 1000 invalid clamps (channel 7)
X429 010 0 0010 1001 invalid ramp rate (channel 0)
X42A 010 0 0010 1010 invalid ramp rate (channel 1)
X42B 010 0 0010 1011 invalid ramp rate (channel 2)
X42C 010 0 0010 1100 invalid ramp rate (channel 3)
X42D 010 0 0010 1101 invalid ramp rate (channel 4)
X42E 010 0 0010 1110 invalid ramp rate (channel 5)
X42F 010 0 0010 1111 invalid ramp rate (channel 6)
X430 010 0 0011 0000 invalid ramp rate (channel 7)
X431 010 0 0011 0001 configuration word 0 illegal bits set (channel 0)
X432 010 0 0011 0010 configuration word 0 illegal bits set (channel 1)
X433 010 0 0011 0011 configuration word 0 illegal bits set (channel 2)
X434 010 0 0011 0100 configuration word 0 illegal bits set (channel 3)
X435 010 0 0011 0101 configuration word 0 illegal bits set (channel 4)
X436 010 0 0011 0110 configuration word 0 illegal bits set (channel 5)
X437 010 0 0011 1011 configuration word 0 illegal bits set (channel 6)
X438 010 0 0011 1000 configuration word 0 illegal bits set (channel 7)
X439 010 0 0011 1001 configuration word 1 illegal bits set (channel 0)
X43A 010 0 0011 1010 configuration word 1 illegal bits set (channel 1)
Table 5.6 1769-OF8C and -OF8V Extended Error Codes
Error Type Hex
Equivalent
(1)
Module
Error
Code
Extended Error
Information
Code
Error Description
Binary Binary
