Configuration Using the RSLogix 5000 Generic Profile for CompactLogix Controllers C-7
Tag addresses are automatically created for configured I/O modules. All local
I/O addresses are preceded by the word Local. These addresses have the
following format:
• Input Data: Local:s.I
• Output Data: Local:s.O
• Configuration Data: Local:s.C
where s is the slot number assigned the I/O modules in the Generic
Profiles.
In order to configure an I/O module, you must open up the configuration tag
for that module by clicking on the plus sign to the left of its configuration tag
in the tag data base.
Configuring Analog Output Modules
To configure the 1769-OF8C or -OF8V module in slot 1, click on the plus
sign left of Local:1.C. Configuration data is entered under the Local:1.C.Data
tag. Click the plus sign to the left of Local:1.C.Data to reveal the 8 integer data
words where configuration data may be entered for the 1769-OF8C or -OF8V
module.
Configuring Analog Input Modules
To configure the input modules in slot 2, click on the plus sign left of
Local:2.C. Click on the plus sign to the left of Local:2.C.Data to reveal the 4
integer data words where the configuration data may be entered for the
module. The tag addresses for these 4 words are Local:2.C.Data[0] through
Local:2.C.Data[3].
