A-2 Specifications
Electrical /EMC: The module has passed testing at the following
levels:
• ESD Immunity
(IEC1000-4-2)
• 4 kV contact, 8 kV air, 4 kV indirect
• Radiated Immunity
(IEC1000-4-3)
• 10 V/m , 80 to 1000 MHz, 80% amplitude
modulation, +900 MHz keyed carrier
• Fast Transient Burst
(IEC1000-4-4)
• 2 kV, 5kHz
• Surge Immunity
(IEC1000-4-5)
• 1kV galvanic gun
• Conducted Immunity
(IEC1000-4-6)
• 10V, 0.15 to 80MHz
(2)
(1)
Failure to use a Class 2 power supply without regulation within these limits could result in improper module
operation.
(2)
Conducted Immunity frequency range may be 150 kHz to 30 MHz if the Radiated Immunity frequency range is
30 MHz to 1000 MHz.
