Publication 1769-UM002B-EN-P - July 2005
Index
Numerics
1769-ADN
configuration example
D-1–D-10
user manual Preface-2
-3 dB frequency 3-7, 3-24
A
A/D
converter
1-7
definition 1-1
abbreviations 1-1
alarm deadband 3-31
alarms
process alarm
3-30
analog input data 3-3, 3-18
analog input module
definition
1-1
overview 1-1
attenuation
cut-off frequency
3-7
definition 1-1
B
bus connector
definition
1-1
locking 2-6
bus interface 1-5
C
calibration 1-10
1769-IF4 A-3
1769-OF2 A-7
channel
definition
1-1
channel diagnostics 5-3
channel reconfiguration time 3-8, 3-24
channel scan time 3-8, 3-24
channel status LED 1-6
channel step response 3-6, 3-23
channel switching time 3-8, 3-24
channel update time
definition
1-1
CMRR. See common mode rejection ratio
common mode rejection
3-6, 3-23, A-3
definition 1-1
common mode rejection ratio
definition
1-1
common mode voltage
definition
1-1
common mode voltage range
definition
1-1
specification A-3
common mode voltage rating 3-6, 3-23
configuration errors 5-6
configuration word
1769-IF4
3-5, 3-22
1769-OF2 4-6
definition 1-2
contacting Rockwell Automation 5-12
current draw
1769-IF4
2-2, A-3
1769-OF2 2-2, A-3
cut-off frequency 3-7, 3-24
D
D/A converter 1-9
definition 1-2
data echo 4-4, 4-21
definition 1-2
data loopback 4-4, 4-21
See also data echo.
data word
definition
1-2
dB
definition
1-2
decibel. See dB.
definition of terms
1-1
DeviceNet adapter
configuration example
??–D-10
user manual publication number
Preface-2
diagnostic bits 4-2, 4-20
differential mode rejection. See normal
mode rejection.
differential operation
definition
1-2
digital filter 3-6, 3-23
definition 1-2
DIN rail mounting 2-8
E
electrical noise 2-4
EMC Directive 2-1
end cap terminator 2-6
error codes 5-6
error definitions 5-4
