Rockwell Automation 1769-IF4 User Manual

Publication 1769-UM002B-EN-P - July 2005
3-12 Module Data, Status, and Channel Configuration for the Input Modules
1.0V to 5V dc Over 5.25V dc 5.5V dc Over-range 32767 (max.) 5250 17407 10625
+5.25V dc 5.25V dc Over-range 32767 (max.) 5250 17407 10625
1.0V to 5.0V dc 5.0V dc Normal 31206 5000 16383 10000
1.0V dc Normal 6243 1000 1 1
0.5V dc 0.5V dc Under-range 3121 (min.) 500 -2048 -1250
Under 0.5V dc 0.0V dc Under-range 3121 (min.) 500 -2048 -1250
0 mA to 20 mA Over 21.0 mA 22.0 mA Over-range 32767 21000 17202 10500
21.0 mA 21.0 mA Over-range 32767 21000 17202 10500
0.0 mA to 20.0 mA 20.0 mA Normal 31206 20000 16383 10000
0.0 mA Normal 0 0 0 0
Under 0.0 mA 0.0 mA Under-range 0 0 0 0
Table 3.7 Valid Input Data
1769-IF4 Input
Range
Input Value Example
Data
Input
Range
Condition
Raw/Propor
tional Data
Engineering
Unit
Scaled-for-
PID
Percent
Full Range
Decimal
Range
Decimal
Range
Decimal
Range
Decimal
Range
