Rockwell Automation Publication 1426-UM001J-EN-P - August 2019 189
Logic Functions Chapter 7
Status_1_Count_xM
Status_1_Count_x1
Status_2_Count_xM
Status_2_Count_x1
Status_3_Count_xM
Status_3_Count_x1
Status_4_Count_xM
Status_4_Count_x1
The semantics for these parameters:
X 1 = value time 1, range = 0…999,999
X M = value time 1 million, range = 0…9,999,999
Combined range (X M, X 1) = 0…9,999,999,999,999
Commands
The following command parameters are found in the
Command.System_Registers
table on page 368.
Command Word One
Set this command word value to set or reset (to zero) a scaled status input counter
value. These values are the selections:
6 = Set Status 1 Count
7 = Set Status 2 Count
8 = Set Status 3 Count
9 = Set Status 4 Count
These commands operate by using the values contained in the tags listed in this
section. The default values are zero. The semantics are the same as described in
the Status
subclause.
