8-2 ArmorStart® ZIP Configuration
Param # Parameter Name Parameter Description
67 AutoRun ZIP Enables ZIP data production on power up
0=Disable; 1=Enable
68 Zone ProducedEPR The Expected Packet Rate in msec. Defines the rate of at which ZIP data is produced. Defaults to 75 msec.
69 Zone ProducedPIT The Production Inhibit Time in msec. Defines the minimum time between Change of State data production
70 Zone #1 MacId The node address of the device whose data is to be consumed for zone 1
71 Zone #2 MacId The node address of the device whose data is to be consumed for zone 2
72 Zone #3 MacId The node address of the device whose data is to be consumed for zone 3
73 Zone #4 MacId The node address of the device whose data is to be consumed for zone 4
74 Zone #1 Health Read Only consumed connection status for zone 1
0=Healthy; 1=Not Healthy
75 Zone #2 Health Read Only consumed connection status for zone 2
0=Healthy; 1=Not Healthy
76 Zone #3 Health Read Only consumed connection status for zone 3
0=Healthy; 1=Not Healthy
77 Zone #4 Health Read Only consumed connection status for zone 4
0=Healthy; 1=Not Healthy
78 Zone #1 Mask Bit enumerated consumed data mask for zone 1. Each bit represents a byte in consumed data up to 8 bytes in length. If a mask bit
is set, the corresponding consumed data byte is placed in the DeviceLogix data table
79 Zone #2 Mask Bit enumerated consumed data mask for zone 2. Each bit represents a byte in consumed data up to 8 bytes in length. If a mask bit
is set, the corresponding consumed data byte is placed in the DeviceLogix data table
80 Zone #3 Mask Bit enumerated consumed data mask for zone 3. Each bit represents a byte in consumed data up to 8 bytes in length. If a mask bit
is set, the corresponding consumed data byte is placed in the DeviceLogix data table
81 Zone #4 Mask Bit enumerated consumed data mask for zone 4. Each bit represents a byte in consumed data up to 8 bytes in length. If a mask bit
is set, the corresponding consumed data byte is placed in the DeviceLogix data table
82 Zone #1 Offset The byte offset into the ZIP data portion of the DeviceLogix data table to place the chosen consumed data bytes for zone 1.
83 Zone #2 Offset The byte offset into the ZIP data portion of the DeviceLogix data table to place the chosen consumed data bytes for zone 2.
84 Zone #3 Offset The byte offset into the ZIP data portion of the DeviceLogix data table to place the chosen consumed data bytes for zone 3.
85 Zone #4 Offset The byte offset into the ZIP data portion of the DeviceLogix data table to place the chosen consumed data bytes for zone 4.
86 Zone #1 EPR The Expected Packet Rate in msec. for the zone 1 consuming connection. If consumed data is not received in 4 times this value, the
zone connection will time out and “Zone #1 Health” will report 1 = Not Healthy.
87 Zone #2 EPR The Expected Packet Rate in msec. for the zone 2 consuming connection. If consumed data is not received in 4 times this value, the
zone connection will time out and “Zone #2 Health” will report 1 = Not Healthy
88 Zone #3 EPR The Expected Packet Rate in msec. for the zone 3 consuming connection. If consumed data is not received in 4 times this value, the
zone connection will time out and “Zone #3 Health” will report 1 = Not Healthy
89 Zone #4 EPR The Expected Packet Rate in msec. for the zone 4 consuming connection. If consumed da
ta is not received in 4 ti
mes this value, the
zone connection will time out and “Zone #4 Health” will report 1 = Not Healthy
90 Zone #1 Control Zone 1 Control Word. Default Bit 1 set, all other bits clear.
Bit0=Security Enable 1=Enable data security
Bit1=COS Cnxn 1=Consume DNet Group 2 COS messages
Bit2=Poll Cnxn 1=Consume DNet Group 2 Poll Response msgs.
Bit3=Strobe Cnxn 1=Consume DNet Group 2 Strobe Response msgs.
Bit4=Multicast Poll 1=Consume Multicast Poll Response messages.
91 Zone #2 Control Zone 2 Control Word. Default Bit 1 set, all other bits clear.
Bit0=Security Enable 1=Enable data security
Bit1=COS Cnxn 1=Consume DNet Group 2 COS messages
Bit2=Poll Cnxn 1=Consume DNet Group 2 Poll Response msgs.
Bit3=Strobe Cnxn 1=Consume DNet Group 2 Strobe Response msgs.
Bit4=Multicast Poll 1=Consume Multicast Poll Response messages.
92 Zone #3 Control Zone 3 Control Word. Default Bit 1 set, all other bits clear.
Bit0=Security Enable 1=Enable data security
Bit1=COS Cnxn 1=Consume DNet Group 2 COS messages
Bit2=Poll Cnxn 1=Consume DNet Group 2 Poll Response msgs.
Bit3=Strobe Cnxn 1=Consume DNet Group 2 Strobe Response msgs.
Bit4=Multicast Poll 1=Consume Multicast Poll Response messages.
93 Zone #4 Control Zone 4 Control Word. Default Bit 1 set, all other bits clear.
Bit0=Security Enable 1=Enable data security
Bit1=COS Cnxn 1=Consume DNet Group 2 COS messages
Bit2=Poll Cnxn 1=Consume DNet Group 2 Poll Response msgs.
Bit3=Strobe Cnxn 1=Consume DNet Group 2 Strobe Response msgs.
Bit4=Multicast Poll 1=Consume Multicast Poll Response messages.
94 Zone #1 Key When the “Security Enable” bit for zone 1 is enabled, this value must match the value of the Device Value Key parameter in the
device whose data is being consumed for zone 1.
95 Zone #2 Key When the “Security Enable” bit for zone 1 is enabled, this value must match the value of the Device Value Key parameter in the
device whose data is being consumed for zone 2.
96 Zone #3 Key When the “Security Enable” bit for zone 1 is enabled, this value must match the value of the Device Value Key parameter in the
device whose data is being consumed for zone 3.
97 Zone #4 Key When the “Security Enable” bit for zone 1 is enabled, this value must match the value of the Device Value Key parameter in the
device whose data is being consumed for zone 4.
98 Device Value Key This value is produced in the last 2 bytes of data when one of the ZIP assemblies is chosen for data production.
99 Zone Ctrl Enable Global enable for ZIP peer-to-peer messaging. This parameter must be disabled before any changes to the ZIP configuration for the
device can be made. 0=Disable; 1=Enable
