Appendix A
Specifications
Bulletin 280G/281G
Electrical Ratings UL/NEMA IEC
Power Circuit
Rated Operation Voltage 380/220V…480/277V AC 380/220V…480/277V AC
Rate Insulation Voltage 600V 600 V
Rated Impulsed Voltage 4 kV 4 kV
Dielectric Withstand 2200V AC 2500V AC
Operating Frequency 50/60 Hz 50/60 Hz
Utilization Category N/A AC-3
Protection Against Shock N/A IP2X
Rated Operating Current Max.
2.5 A
5.5 A
16 A
Control
Circuit
Rated Operation Voltage
Safety Products only: 24V DC (+10%, -15%) A2 (should be grounded at voltage source)
120V AC (+10%, -15%) A2 (should be grounded at voltage source)
Rated Short Circuit 1 kA
SCPD 10 A circuit breaker or equivalent
Rate Insulation Voltage 250V 250V
Rated Impulsed Voltage — 4 kV
Dielectric Withstand 1500V AC 2000V AC
Overvoltage Category — III
Operating Frequency 50/60 Hz 50/60 Hz
Short Circuit
Protection
SCPD Performance Type 1
Current Rating Voltage 480Y/277V
0.5…2.5 A
Sym. Amps RMS
65kA
1.1…5.5 A
3.2…16 A 30kA
SCPD Fuses,
only fuse types: J, CC, and T
100 A maximum
SCPD UL 489 Circuit Breakers 100 A maximum
Safety Products Only
C10 Base: 100 A maximum
C25 Base: 60 A maximum
SCPD List Size per NEC Group Motor
Power Requirements
Units Non-Safety Products Safety Products
Control Voltage Volts 120V AC, 50/60 Hz 24V DC
Contactor (Pick Up) Amps 0.58 plus the motor brake current 1.09
Contactor (Hold In) Amps 0.08 plus the motor brake current 30
120V AC Brake (Pick Up) Amps — motor brake pick-up current
120V AC Brake (Hold In) Amps — motor brake hold-in current
Total Control Power (Pick Up) VA (W) 70 (26)
Total Control Power (Hold In) VA (W) 9 (7.2)
Input Ratings
Rated Operation Voltage 24V DC
Input On-State Voltage Range 10…26V DC
Input On-state Current
3.0 mA @ 10V DC
7.2 mA @ 24V DC
Input Off-state Voltage Range 0…5V DC
Input Off-state Current <1.5 mA
Input Filter — Software Selectable
Off to On Settable from 0…64 ms in 1 ms increments
On to Off Settable from 0…64 ms in 1 ms increments
Input Compatibility N/A IEC 1+
Number of inputs 6
Sensor Source
Voltage Status Only 11…25V DC from DeviceNet™
Current Available 50 mA MAX per Input, 300 mA Total
