Appendix C
Bulletin 284G CIP Information
Electronic Data Sheets Electronic Data Sheets (EDS) files are specially formatted ASCII files that
provide all of the information necessary for a configuration tool (e.g.,
RSNetWorx™ for DeviceNet™ Revision 3.21 Service Pack 2 or later) to
access and alter parameters of the device. The EDS file contains all of the
device information: number of parameter, groupings, parameter name,
minimum, maximum, and default values, units, data format, and scaling.
EDS files for all the ArmorStart® Distributed Motor Controllers units are
available from the Internet at www.ab.com/networks/eds.
They may also be built automatically by some configuration tools since
much of the information necessary for an EDS file may be extracted from
the ArmorStart Distributed Motor Controller.
VFD Type Product Codes and
Name Strings
Product codes for the Bulletin 284G variable frequency drives are based on
the Horse Power Rating and Supply Voltage rating of the Distributed Motor
Controller. Table C.1 lists the product codes and name strings for the
Bulletin 284G Distributed Motor Controllers:
Table C.1 Bulletin 284G Product Codes and Name Strings
Table C.2 Bulletin 284G Safety Product Codes and Name Strings
284G
Device
Type ➊
Product
Code
Hp Supply Voltage Name String Drive Type
22 0x592 0.50 480V AC ArmorStart 284G PF40 480V 0.5 Hp PF40
22 0x594 1 480V AC ArmorStart 284G PF40 480V 1 Hp PF40
22 0x596 2 480V AC ArmorStart 284G PF40 480V 2 Hp PF40
22 0x597 3 480V AC ArmorStart 284G PF40 480V 3 Hp PF40
22 0x598 5 480V AC ArmorStart 284G PF40 480V 5 Hp PF40
22 0x599 7.5 480V AC ArmorStart 1000 PF40 480V 7.5 Hp PF40
22 0x59A 10 480V AC ArmorStart 1000 PF40 480V 10 Hp PF40
22 0x59B 15 480V AC ArmorStart 1000 PF40 480V 15 Hp PF40
284G
Device
Type ➊
Product
Code
Hp Supply Voltage Name String Drive Type
22 0x5C2 0.50 480V AC ArmorStart 284G PF40 480V 0.5 Hp PF40
22 0x5C4 1 480V AC ArmorStart 284G PF40 480V 1 Hp PF40
22 0x5C6 2 480V AC ArmorStart 284G PF40 480V 2 Hp PF40
22 0x5C7 3 480V AC ArmorStart 284G PF40 480V 3 Hp PF40
22 0x5C8 5 480V AC ArmorStart 284G PF40 480V 5 Hp PF40
22 0x5C9 7.5 480V AC ArmorStart 1000 PF40 480V 7.5 Hp PF40
22 0x5CA 10 480V AC ArmorStart 1000 PF40 480V 10 Hp PF40
22 0x5CB 15 480V AC ArmorStart 1000 PF40 480V 15 Hp PF40
➊ 22= Motor Starter
